| INCH | SIZE | RIM TYPE | FACE | INSET | HOLE | P.C.D. | DRILL | BORE | BIG CALIPER CLEARANCE |
|---|---|---|---|---|---|---|---|---|---|
| ( )内はリム深さ | |||||||||
| 18 | 8 1/2J | S(39mm) | FACE-1 | 35 | 5 | 100 | φ29-φ15 | φ65 |
▼
|
| 35 | 5 | 114.3 | φ29-φ13 | φ73.1 |
▽Θη■⊿◎♯△○☆〓
|
||||
| 9J | M(46mm) | FACE-1 | 30 | 5 | 100 | φ29-φ15 | φ65 |
▼
|
|
| FACE-2 | 20 | 5 | 114.3 | φ29-φ13 | φ73.1 |
▽Θη■⊿♯△○☆〓
|
|||
| 9 1/2J | M(46mm) | FACE-1 | 30 | 5 | 114.3 | φ29-φ13 | φ73.1 |
▽Θη■⊿♯△○☆〓
|
|
| FACE-2 | 20 |
▽Θη■⊿♯△○☆〓
|
|||||||
| L(70mm) | 0 |
▽Θη■⊿♯△○☆〓
|
|||||||
| 10J | L(70mm) | FACE-1 | 15 | 5 | 114.3 | φ29-φ13 | φ73.1 |
▽Θη■⊿♯△○☆〓
|
|
| LL(95mm) | FACE-2 | -25 |
▽Θη■⊿♯△○☆〓
|
||||||
| 10 1/2J | L(70mm) | FACE-2 | 15 | 5 | 114.3 | φ29-φ13 | φ73.1 |
▽Θη■⊿♯△○☆〓
|
|
| FACE-3 | 0 |
▽Θη■⊿◎♯△○☆◆〓
|
|||||||
| LL(95mm) | -25 |
▽Θη■⊿◎♯△○★◆〓
|
|||||||
| 11J | LL(95mm) | FACE-2 | 0 | 5 | 114.3 | φ29-φ13 | φ73.1 |
▽Θη■⊿♯△○★〓
|
|
| LLL(108mm) | FACE-3 | -30 |
▽Θη■⊿◎♯△○★◆〓
|
||||||
| 11 1/2J | LL(95mm) | FACE-3 | -20 | 5 | 114.3 | φ29-φ13 | φ73.1 |
▽Θη■⊿◎♯△○☆◆〓
|
|
| 12J | LLL(108mm) | FACE-3 | -33 | 5 | 114.3 | φ29-φ13 | φ73.1 |
▽Θη■⊿◎♯△○☆◆〓
|
| INCH | SIZE | RIM TYPE | FACE | INSET | HOLE | P.C.D. | DRILL | BORE | CALIPER CLEARANCE |
|---|---|---|---|---|---|---|---|---|---|
| ( )内はリム深さ | キャリパー対応車両例 | ||||||||
| 18 | 9 1/2J | M(46mm) | FACE-2 | 20 | 5 | 120 | φ29-φ15 | φ72.6 | HONDA CIVIC TYPE R(FK8), BMW M3(E46, E92), M4(F82)(Carbon-Cブレーキ除く) M2(F87)(Compettition除く） |
| 10 1/2J | L(70mm) | FACE-2 | 15 | 5 | 120 | φ29-φ15 | φ72.6 | HONDA CIVIC TYPE R(FK8), BMW M3(E46, E92), M4(F82)(Carbon-Cブレーキ除く) M2(F87)(Compettition除く） |
