| INCH | SIZE | FACE | INSET | HOLE | P.C.D. | DRILL | BORE | BIG CALIPER CLEARANCE |
|---|---|---|---|---|---|---|---|---|
| ビッグキャリパー対応マーク | ||||||||
| 17 | 7J | FACE-1 | 44(24) | 4 | 100 | φ29-φ15 | φ65 | - |
| 7 1/2J | FACE-3 | 31(25) | 4 | 100 | φ29-φ15 | φ65 | - | |
| FACE-1 | 37(31) | 4 | 100 | φ29-φ15 | φ65 |
Ψ
|
||
| 47(28) | 5 | 100 | φ29-φ15 | φ65 | - | |||
| 47(28) | 5 | 114.3 | φ32-φ15 | φ73.1 | - | |||
| 43(32) | 5 | 114.3 | φ32-φ15 | φ73.1 |
▽θ＃▲
|
|||
| 8J | FACE-2 | 37(27) | 5 | 114.3 | φ32-φ15 | φ73.1 |
▽θ＃▲
|
|
| 8 1/2J | FACE-2 | 39(31) | 4 | 100 | φ29-φ15 | φ65 |
Ψ
|
|
| 44(26) | 5 | 100 | φ29-φ15 | φ65 |
▼
|
|||
| 39(31) | 5 | 114.3 | φ32-φ15 | φ73.1 |
▽θ＃▲γΩ
|
|||
| 29(41) | 5 | 114.3 | φ32-φ15 | φ73.1 |
▽θ＃▲γΩΣ
|
|||
| 9J | FACE-3 | 44(23) | 5 | 100 | φ29-φ15 | φ65 |
▼
|
|
| 44(23) | 5 | 114.3 | φ32-φ15 | φ73.1 |
▽θ＃▲
|
|||
| FACE-4 | 21(31) | 5 | 114.3 | φ32-φ15 | φ73.1 |
▽θ＃▲γΩΣ
|
||
| 9 1/2J | FACE-4 | 45(21) | 5 | 100 | φ29-φ15 | φ65 | - | |
| 18(41) | 5 | 114.3 | φ32-φ15 | φ73.1 |
▽θ＃▲γΩΣ
|
|||
| 35(31) | 5 | 114.3 | φ32-φ15 | φ73.1 |
▽θ＃▲γΩ
|
|||
| 40(26) | 5 | 114.3 | φ32-φ15 | φ73.1 |
▽θ＃▲
|
| INCH | SIZE | FACE | INSET | HOLE | P.C.D. | DRILL | BORE | BIG CALIPER CLEARANCE |
|---|---|---|---|---|---|---|---|---|
| ビッグキャリパー対応マーク | ||||||||
| 18 | 8 1/2J | FACE-3 | 45(21) | 5 | 100 | φ29-φ15 | φ65 |
▼
|
| FACE-3 | 45(21) | 5 | 114.3 | φ32-φ15 | φ73.1 |
ηθ■⊿□●〓
|
||
| 9J | FACE-3 | 52(20) | 5 | 100 | φ29-φ15 | φ65 |
▼
|
|
| 45(27) | 5 | 114.3 | φ32-φ15 | φ73.1 |
η▽θ■⊿＃△○★〓
|
|||
| 9 1/2J | FACE-4 | 45(22) | 5 | 100 | φ29-φ15 | φ65 |
▼
|
|
| FACE-4 | 45(22) | 5 | 114.3 | φ32-φ15 | φ73.1 |
ηθ■⊿□▲α●〓
|
||
| FACE-4 | 22(33) |
η▽θ■⊿◎＃△○☆◇〓
|
||||||
| FACE-4 | 35(20) |
η▽θ■⊿◎＃△○★◆〓
|
||||||
| 10J | FACE-4 | 40(22) | 5 | 114.3 | φ32-φ15 | φ73.1 |
η▽θ■⊿◎＃△○★◆〓
|
|
| FACE-5 | 20(38) |
η▽θ■⊿◎＃△○☆◇〓
|
||||||
| 10 1/2J | FACE-5 | 22(31) | 5 | 114.3 | φ32-φ15 | φ73.1 |
η▽θ■⊿◎＃△○☆◇〓
|
|
| FACE-5 | 15(38) |
η▽θ■⊿◎＃△○☆◇〓
|
||||||
| 11J | FACE-5 | 15(44) | 5 | 114.3 | φ32-φ15 | φ73.1 |
η▽θ■⊿◎＃△○☆◇〓
|
| INCH | SIZE | FACE | INSET | HOLE | P.C.D. | DRILL | BORE | CALIPER CLEARANCE |
|---|---|---|---|---|---|---|---|---|
| キャリパー対応車両例 | ||||||||
| 17 | 7 1/2J | FACE-1 | 36(32) | 4 | 98 | φ29-φ15 | φ65 | FIAT ABARTH595 |
| 39(29) | 5 | 112 | φ32-φ15 | φ66.6 | MINI JCW(F56) | |||
| 8J | FACE-2 | 44(27) | 4 | 100 | φ29-φ15 | φ65 | NDロードスター(RF),ABARTH124SPIDER | |
| 34(30) | 4 | 100 | φ29-φ15 | φ65 | ABARTH124SPIDER |
| INCH | SIZE | FACE | INSET | HOLE | P.C.D. | DRILL | BORE | CALIPER CLEARANCE |
|---|---|---|---|---|---|---|---|---|
| キャリパー対応車両例 | ||||||||
| 18 | 8 1/2J | FACE-3 | 42 | 5 | 112 | φ32-φ15 | φ66.6 | VW GOLF V/Ⅵ/Ⅶ, AUDI TT(8J) |
| 9J | FACE-4 | 23 | 5 | 120 | φ32-φ15 | φ72.6 | BMW M2(F87)Fr | |
| FACE-4 | 27 | 112 | φ32-φ15 | φ66.6 | TOYOTA SUPRA(A90)Fr | |||
| 9 1/2J | FACE-4 | 45 | 5 | 120 | φ32-φ15 | φ72.6 | HONDA CIVIC TYPE R(FK8) | |
| FACE-4 | 38 | HONDA CIVIC TYPE R(FK8) | ||||||
| FACE-5 | 20 | BMW M3(E92)Fr, M4(F82)Fr, M2(F87)Fr* | ||||||
| FACE-5 | 20 | 112 | φ32-φ15 | φ66.6 | TOYOTA SUPRA(A90)Fr | |||
| 10J | FACE-4 | 34 | 5 | 120 | φ32-φ15 | φ72.6 | BMW M2(F87)Rr | |
| FACE-4 | 34 | 112 | φ32-φ15 | φ66.6 | TOYOTA SUPRA(A90)Rr | |||
| 10 1/2J | FACE-5 | 30 | 5 | 120 | φ32-φ15 | φ72.6 | BMW M3(E92)Rr, M4(F82)Rr, M2(F87)Rr* | |
| FACE-5 | 30 | 112 | φ32-φ15 | φ66.6 | TOYOTA SUPRA(A90)Rr |
