| INCH | SIZE | FACE | CENTER | INSET | HOLE | P.C.D. | DRILL | BORE | BIG CALIPER CLEARANCE |
|---|---|---|---|---|---|---|---|---|---|
| (mm) | ビッグキャリパー対応マーク | ||||||||
| 19 | 8 1/2J | FACE-1 | S | 45(36) | 5 | 114.3 | φ29-φ13 | φ73.1 |
η⊿〓
|
| 9 1/2J | FACE-3 | S | 22(46) | 5 | 114.3 | φ29-φ13 | φ73.1 |
▽Θη■⊿◎#△◯★◇〓
|
|
| 10 1/2J | FACE-4 | S | 22(45) | 5 | 114.3 | φ29-φ13 | φ73.1 |
▽Θη■⊿◎#△◯★◇〓
|
|
| L | 12(42) |
▽Θη■⊿◎#△◯☆◇〓
|
|||||||
| 20 | 10J | FACE-3 | L | 30(25) | 5 | 114.3 | φ29-φ15 | φ73.1 |
▽Θη■⊿◎◇〓
|
| 11J | FACE-4 | L | 15(34) | 5 | 114.3 | φ29-φ15 | φ73.1 |
▽Θη■⊿◎#△◯★◇〓
|
|
| 12J | FACE-4 | L | 20(41) | 5 | 114.3 | φ29-φ15 | φ73.1 |
▽Θη■⊿◎#△◯☆◇〓
|
| INCH | SIZE | FACE | CENTER | INSET | HOLE | P.C.D. | DRILL | BORE | CALIPER CLEARANCE |
|---|---|---|---|---|---|---|---|---|---|
| キャリパー対応車両例 | |||||||||
| 19 | 9J | FACE-3 | S | 27 | 5 | 112 | φ29-φ15 | φ66.6 | Supra(A90)Fr*, BMW Z4(G29)Fr* |
| 9 1/2J | FACE-4 | S | 20 | 5 | 112 | φ29-φ15 | φ66.6 | Supra(A90)Fr*, BMW Z4(G29)Fr* | |
| FACE-3 | S | 36 | 5 | 120 | φ29-φ15 | φ72.6 | HONDA CIVIC TYPE-R(FK-8)* | ||
| 10J | FACE-4 | S | 34 | 5 | 112 | φ29-φ15 | φ66.6 | Supra(A90)Rr*, BMW Z4(G29)Rr* |
| INCH | SIZE | FACE | CENTER | INSET | HOLE | P.C.D. | DRILL | BORE | FITTING |
|---|---|---|---|---|---|---|---|---|---|
| mm | 対象車種 | ||||||||
| 19 | 8 1/2J | FACE-1 | S | 40 | 5 | 130 | φ32-φ15 | φ71.6 | PORSCHE CAYMAN(981,987)Fr |
| 10J | FACE-3 | S | 36 | 5 | 130 | φ32-φ15 | φ71.6 | PORSCHE CAYMAN(981,987)Rr |
