15inch | ||||||||||
15inch | WIDTH | INSET | P.C.D. | HOLES | BORE | DS | MDG | WEIGHT | ||
5J | 45 | 100 | ※4 | φ67 | ¥34650 | ¥20920(tax込) | ¥34650 | ¥20920(tax込) | 5.6kg~ | |
5.5J | 45 | 100 | ※4 | φ67 | ¥35200 | ¥21210(tax込) | ¥35200 | ¥21210(tax込) | 5.8kg~ | |
6J | 45 | 100 | ※4 | φ67 | ¥35750 | ¥21510(tax込) | ¥35750 | ¥21510(tax込) | 6.1kg~ | |
38 | 100 | 5 | φ67 | ¥35750 | ¥21510(tax込) | ¥35750 | ¥21510(tax込) | 6.1kg~ | ||
16inch | ||||||||||
16inch | WIDTH | INSET | P.C.D. | HOLES | BORE | DS | MDG | WEIGHT | ||
5.5J | 45 | 100 | ※4 | φ67 | ¥38500 | ¥22990(tax込) | ¥38500 | ¥22990(tax込) | 6.3kg~ | |
6.5J | 45 | 100 | ※4 | φ67 | ¥39600 | ¥23590(tax込) | ¥39600 | ¥23590(tax込) | 6.7kg~ | |
38 | 100 | 5 | φ67 | ¥39600 | ¥23590(tax込) | ¥39600 | ¥23590(tax込) | 6.7kg~ | ||
38 | 100 | ※4 | φ67 | ¥39600 | ¥23590(tax込) | ¥39600 | ¥23590(tax込) | 6.7kg~ | ||
17inch | ||||||||||
17inch | WIDTH | INSET | P.C.D. | HOLES | BORE | DS | MDG | WEIGHT | ||
7J | 48 | 114.3 | 5 | φ75 | ¥44550 | ¥26260(tax込) | ¥44550 | ¥26260(tax込) | 8.0kg~ | |
48 | 112 | 5 | φ75 | ¥44550 | ¥26260(tax込) | ¥44550 | ¥26260(tax込) | 8.0kg~ | ||
48 | 100 | 5 | φ75 | ¥44550 | ¥26260(tax込) | ¥44550 | ¥26260(tax込) | 8.0kg~ | ||
48 | 100 | 4 | φ75 | ¥44550 | ¥26260(tax込) | ¥44550 | ¥26260(tax込) | 8.0kg~ | ||
42 | 100 | 4 | φ75 | ¥44550 | ¥26260(tax込) | ¥44550 | ¥26260(tax込) | 8.0kg~ | ||
7.5J | 48 | 114.3 | 5 | φ75 | ¥45650 | ¥26860(tax込) | ¥45650 | ¥26860(tax込) | 8.2kg~ | |
48 | 112 | 5 | φ75 | ¥45650 | ¥26860(tax込) | ¥45650 | ¥26860(tax込) | 8.2kg~ | ||
48 | 100 | 5 | φ75 | ¥45650 | ¥26860(tax込) | ¥45650 | ¥26860(tax込) | 8.2kg~ | ||
8J | 48 | 114.3 | 5 | φ75 | ¥46750 | ¥27450(tax込) | ¥46750 | ¥27450(tax込) | 8.3kg~ | |
48 | 112 | 5 | φ75 | ¥46750 | ¥27450(tax込) | ¥46750 | ¥27450(tax込) | 8.3kg~ | ||
48 | 100 | 5 | φ75 | ¥46750 | ¥27450(tax込) | ¥46750 | ¥27450(tax込) | 8.3kg~ | ||
35 | 114.3 | 5 | φ75 | ¥46750 | ¥27450(tax込) | ¥46750 | ¥27450(tax込) | 8.3kg~ | ||
34 | 120 | 5 | φ72.5 | ¥46750 | ¥27450(tax込) | ¥46750 | ¥27450(tax込) | 8.3kg~ | ||
8.5J | 45 | 100 | 4 | φ75 | ¥47850 | ¥28040(tax込) | ¥47850 | ¥28040(tax込) | 8.4kg~ | |
18inch | ||||||||||
18inch | WIDTH | INSET | P.C.D. | HOLES | BORE | DS | MDG | WEIGHT | ||
7.5J | 48 | 114.3 | 5 | φ75 | ¥52250 | ¥30420(tax込) | ¥52250 | ¥30420(tax込) | 8.6kg~ | |
48 | 112 | 5 | φ75 | ¥52250 | ¥30420(tax込) | ¥52250 | ¥30420(tax込) | 8.6kg~ | ||
48 | 100 | 5 | φ75 | ¥52250 | ¥30420(tax込) | ¥52250 | ¥30420(tax込) | 8.6kg~ | ||
8J | 50 | 112 | 5 | φ75 | ¥53350 | ¥31010(tax込) | ¥53350 | ¥31010(tax込) | 8.8kg~ | |
50 | 100 | 5 | φ75 | ¥53350 | ¥31010(tax込) | ¥53350 | ¥31010(tax込) | 8.8kg~ | ||
45 | 114.3 | 5 | φ75 | ¥53350 | ¥31010(tax込) | ¥53350 | ¥31010(tax込) | 8.8kg~ | ||
35 | 114.3 | 5 | φ75 | ¥53350 | ¥31010(tax込) | ¥53350 | ¥31010(tax込) | 8.8kg~ | ||
34 | 120 | 5 | φ72.5 | ¥53350 | ¥31010(tax込) | ¥53350 | ¥31010(tax込) | 8.8kg~ | ||
8.5J | 47 | 120 | 5 | φ72.5 | ¥54450 | ¥31610(tax込) | ¥54450 | ¥31610(tax込) | 9.1kg~ | |
45 | 114.3 | 5 | φ75 | ¥54450 | ¥31610(tax込) | ¥54450 | ¥31610(tax込) | 9.1kg~ | ||
45 | 112 | 5 | φ75 | ¥54450 | ¥31610(tax込) | ¥54450 | ¥31610(tax込) | 9.1kg~ | ||
35 | 114.3 | 5 | φ75 | ¥54450 | ¥31610(tax込) | ¥54450 | ¥31610(tax込) | 9.1kg~ | ||
9J | 45 | 114.3 | 5 | φ75 | ¥55550 | ¥32200(tax込) | ¥55550 | ¥32200(tax込) | 9.2kg~ | |
45 | 112 | 5 | φ75 | ¥55550 | ¥32200(tax込) | ¥55550 | ¥32200(tax込) | 9.2kg~ | ||
35 | 114.3 | 5 | φ75 | ¥55550 | ¥32200(tax込) | ¥55550 | ¥32200(tax込) | 9.2kg~ | ||
19inch | ||||||||||
19inch | WIDTH | INSET | P.C.D. | HOLES | BORE | DS | MDG | WEIGHT | ||
7.5J | 48 | 114.3 | 5 | φ75 | ¥59400 | ¥34280(tax込) | ¥59400 | ¥34280(tax込) | 9.2kg~ | |
48 | 100 | 5 | φ75 | ¥59400 | ¥34280(tax込) | ¥59400 | ¥34280(tax込) | 9.2kg~ | ||
8J | 45 | 114.3 | 5 | φ75 | ¥60500 | ¥34870(tax込) | ¥60500 | ¥34870(tax込) | 9.5kg~ | |
40 | 114.3 | 5 | φ75 | ¥60500 | ¥34870(tax込) | ¥60500 | ¥34870(tax込) | 9.5kg~ | ||
45 | 112 | 5 | φ75 | ¥60500 | ¥34870(tax込) | ¥60500 | ¥34870(tax込) | 9.5kg~ | ||
45 | 100 | 5 | φ75 | ¥60500 | ¥34870(tax込) | ¥60500 | ¥34870(tax込) | 9.5kg~ | ||
8.5J | 45 | 114.3 | 5 | φ75 | ¥61600 | ¥35470(tax込) | ¥61600 | ¥35470(tax込) | 9.7kg~ | |
35 | 114.3 | 5 | φ75 | ¥61600 | ¥35470(tax込) | ¥61600 | ¥35470(tax込) | 9.7kg~ | ||
45 | 112 | 5 | φ75 | ¥61600 | ¥35470(tax込) | ¥61600 | ¥35470(tax込) | 9.7kg~ | ||
30 | 112 | 5 | φ75 | ¥61600 | ¥35470(tax込) | ¥61600 | ¥35470(tax込) | 9.7kg~ | ||
45 | 100 | 5 | φ75 | ¥61600 | ¥35470(tax込) | ¥61600 | ¥35470(tax込) | 9.7kg~ | ||
9J | 45 | 114.3 | 5 | φ75 | ¥62700 | ¥36060(tax込) | ¥62700 | ¥36060(tax込) | 9.9kg~ | |
45 | 112 | 5 | φ75 | ¥62700 | ¥36060(tax込) | ¥62700 | ¥36060(tax込) | 9.9kg~ | ||
35 | 112 | 5 | φ75 | ¥62700 | ¥36060(tax込) | ¥62700 | ¥36060(tax込) | 9.9kg~ | ||
9.5J | 48 | 112 | 5 | φ75 | ¥63800 | ¥36660(tax込) | ¥63800 | ¥36660(tax込) | 10.2kg~ | |
35 | 112 | 5 | φ75 | ¥63800 | ¥36660(tax込) | ¥63800 | ¥36660(tax込) | 10.2kg~ | ||
45 | 114.3 | 5 | φ75 | ¥63800 | ¥36660(tax込) | ¥63800 | ¥36660(tax込) | 10.2kg~ |
(※)… M12ボルトのみ対応(他サイズはM14ボルト対応)
